Product Data Sheet

ATP1277W



Adaptive Technology Passive Infrared Wall Switch
Hubbell ATP series Adaptive Technology wall switch sensors are dual voltage rated for use on 120 or 277V AC applications. These sensors feature a push button ambient light level control that allows for quick, accurate setting of the ambient light level threshold.

Hubbell Wiring Device-Kellems Product Specifications
 Product  Indoor Sensor
 Application  Wall Switch
 # of Poles  Single
 Sensing Technology  Passive Infrared
 Coverage Area  1200 Sq. Ft.
 Adaptive  Yes
 Photocell  Yes
 Power Supply  120/277V AC, 60 Hz
 Color
 Agency Approvals  UL listed, CUL listed
 Lens Material  Polyethylene
 Dimensions  Face 2.61"H x 1.29"W, 0.71"D (from wall out)
 Housing Material  Flame retardant UL 94 V-0 ABS
 Operating Temperature  32 F to 122 F (0 C to 50 C) with rate of change not exceeding 20 F (11 C) per hour
 Operating Humidity  20% to 90% noncondensing relative humidity
 Storage Temperature  -40 F to 150 F (-40 C to 65 C)
 Storage Humidity  20% to 90% noncondensing relative humidity
 Time Delay  Digital, test (20 seconds), adaptive 5 to 30 minutes
 Ambient Light  Digital, push button, 30 to 300 foot candles
 Passive Infrared Sensing Indicator  Red LED
 Mounting Height  42 to 54 inches above floor
 Incandescent Load Capacity  0 to 800 watts
 120V Ballast Load Capacity  0 to 800 watts
 277V Ballast Load Capacity  0 to 1200 watts
 Front Press Switch  Auto/Momentary Off (30 minutes after last motion, switch returns to automatic mode)
 Service Switch  Auto/Off












Hubbell Wiring Device-Kellems
