| Product Specifications |
| Type |
Motor Starters. |
| Motor Starter Type |
AC Manual. |
| Actuator |
Toggle. |
| Switch Contact Type |
Double Pole. |
| Amperage |
40A |
| Amperage/Voltage Rating |
600V AC |
| Wiring Style |
Back Wired |
| Termination Type |
Combo Philips/Slotted/Robertson
|
| Motor Starter Variety |
Switch Only. |
| Base Material |
Thermoset. |
| Face Material |
Thermoset. |
| Toggle/Actuator Material |
Nylon. |
| Terminals |
High Performance Copper Alloy.
|
| Mounting Yoke |
Zinc Plated Steel. |
| Contacts |
Silver Cadmium Oxide. |
| Movable Contact Arm |
High Performance Copper Alloy.
|
| Terminal Screws |
Brass. |
| Dielectric Voltage |
Withstands 2200V Minimum. |
| Max. Working Voltage |
600V AC |
| Overload |
6 times full load current for
50 cycles. |
| Temp. Rise |
50 deg. C maximum at rated
current. |
| Max. Continuous Current |
40A |
| Endurance |
2 times full load current for
1,000 cycles followed by 5,000 cycles w/o load. |
| Terminal Accomodation |
#8 AWG max. |
| Flammibility |
UL 94 V2 min.. |
| Operating Temperature |
Maximum continuous 75 deg.
C- Minimum -40 dec. C (w/o impact). |
| UL Certification |
UL Listed, File E70402, Guide
#NLRV. |
| Standards |
Complies with UL 508. |
