Isolated Ground Straight Blade
Receptacle.
|
| Product Specifications |
| Blade Style |
Straight Blade. |
| Amperes |
20A |
| Voltage |
125V |
| Poles and Wires |
2 Pole, 3 Wire. |
| Receptacle Style |
Single. |
| Color |
Orange. |
| Grade |
Hospital. |
| Receptacle Variation |
Standard. |
| NEMA Configuration |
5-20R |
| UL Listing |
File #E2258- Guide #RTRT. |
| CSA Certification |
File #LR16215- Guide #365E1.
|
| Fed Spec |
Complies with performance requirements
of Federal Specification WC596 (where applicable). |
| Complies with: |
NEMA Standards WD-1, WD-6,
UL 498 and CSA C22.2 No. 42-M 1984. |
| Overseas Approvals |
NOM. |
| Top Material |
Nylon. |
| Base Material |
Nylon. |
|
