| Hubbell Wiring Device-Kellems Product
Specifications |
| Blade Style |
Straight Blade |
| Amperes |
30A |
| Voltage |
250V |
| Poles and Wires |
2 Pole, 3 Wire Grounding |
| Wiring Style |
Back Wire |
| Color |
 |
| Face Shape |
Single Round |
| Grade |
Industrial |
| Surge Suppression? |
No |
| Outlet Count |
1 |
| NEMA Configuration |
6-30R |
| Horsepower |
2 HP |
| Description |
Heavy Duty Straight Blade
Single Receptacle |
| Type |
2 Pole, 3 Wire, Grounding
|
| Rating |
30A, 250V |
| Certification |
UL Listed File E2186 Listed to
UL Standards 498 Receptacles , Certified to CSA Standard 22.2M 42M
|
| Top Material |
Phenolic |
| Base Material |
Phenolic |
| Ground Contact Material |
.040" Brass |
| Mounting Strap Material |
.062" Steel - Zn Plate |
| Binding Screws Material |
Steel - Plated |
| Ground Screw Material |
Steel- Plated |
| Mounting Screws
Material |
Steel-Zinc Plated |
| Contacts Material |
.040" Brass |
| Clamping Plate Material |
.060" Brass |
| Dielectric Voltage
Withstand |
Withstands 2,000V minimum.
|
| Current Interrupting |
Certified for current
interrupting at full rated current. |
| Temperature Rise |
Max 30 deg C temp rise at full
rated current after 50 cycles of overload at 150% of rated current
with direct current |
| Terminal Identification |
Terminals identified in
accordance with UL 498 (Brass, White, Green). |
| Terminal Accommodation |
#12 - #4 AWG copper stranded or
solid conductor only. |
| Product Identification |
Ratings are permanent part of
device. |
| Operating Temperatures |
Maximum continuous 60°C,
minimum -40°C (w/o impact). |
| Flammability |
UL 94 V0
|
